PON Features

ITU-T G.984.x

Up to 20 Km PON transmission distance

Passive access to 128 terminals on a single fiber

Uplink and downlink triple churning encrypted function with 128Bits

ONU terminal legitimacy certification, illegal ONU registration event reported

DBA, with granularity 1K bit / s

Standard OMCI management functions

ONU batch software upgrade, fixed time upgrade, real-time upgrade

PON port optical power detection

L2 Features

MAC

MAC Black Hole

Port MAC Limit

64K MAC , with 2MB cache exchange chip and 720MB external cache

VLAN

4K VLAN entries

Port-based/MAC-based/protocol/IP subnet-based

QinQ and flexible QinQ (Stacked VLAN)

VLAN Swap and VLAN Remark

Support PVLAN to realize port isolation and save public-vlan resources

GVRP

Spanning Tree

STP/RSTP/MSTP

Remote loop detecting

Port

Bi-directional bandwidth control

Static link aggregation and LACP(Link Aggregation Control Protocol)

Port mirroring

Security Features

User’s Security

Anti-ARP-spoofing

Anti-ARP-flooding

IP Source Guard

Port Isolation

MAC address binding to the port and MAC address filtering

IEEE 802.1x and AAA/Radius authentication

Device Security

Anti-DOS attack(such as ARP, Synflood, Smurf, ICMP attack), ARP

detection, worm and Msblaster worm attack

SSHv2 Secure Shell

SNMP v3 encrypted management

Security IP login through Telnet

Hierarchical management and password protection of users

Network Security

ARP traffic detection based on MAC address per user

ARP packet suppression based on ARP traffic detection or block users

one-click binding based on dynamic ARP tables

IP+VLAN+MAC+Port binding

L2 to L7 ACL flow filtration mechanism on the 80 bytes of the head of user-defined packet

Supports port broadcast / multicast suppression and dangerous port auto-shutdown

URPF

DHCP Option82

PPPoE+

Support plain text and MD5 cipher text authentication for OSPF, RIPv2 and BGPv4 packets

Service Features

ACL

Standard and extended ACL

Time Range ACL

Support flow classification and flow definition based on source/destination MAC address, VLAN, 802.1p, ToS, DiffServ, source/destination IP(IPv4/IPv6) address, TCP/UDP port number, protocol type, etc

Support L2 ~ L7 deep IP packet header 80 bytes of packet filtering

QoS

Support rate-limit for packet sending/receiving speed of port or self-defined flow, providing general flow monitor and two-speed tri-color monitor of self-defined flow

CAR(Committed Access Rate), Traffic Shaping and flow statistics

Support message mirroring and message redirection for ports or custom flows

Support priority marking for ports or custom flows and provides Remark capabilities for 802.1P, DSCP priority

Support advanced queue scheduling based on port or custom flow. Each port / stream supports 4 priority queues, providing WRR, SP and FIFO queue scheduling algorithms

Support congestion avoidance mechanism, including Tail-Drop, WRED and other functions

IPv4

ARP Proxy

DHCP Relay

DHCP Server

Static Routing

RIPv1/v2

OSPFv2

BGPv4

Equivalent Routing

Routing Strategy

IPv6

ICMPv6

ICMPv6 redirection

DHCPv6

ACLv6

OSPFv3

RIPng

BGP4+

manual tunneling

ISATAP

6to4

IPv6

IPv4 dual-stack

Multicast

IGMPv1/v2/v3

IGMPv1/v2/v3 Snooping

IGMP Filter

MVR and cross VLAN multicast copy

IGMP Fast leave

IGMP Proxy

PIM-SM/PIM-DM/PIM-SSM

PIM-SMv6、PIM-DMv6、PIM-SSMv6

MLDv2/MLDv2 Snooping

Reliability

Loop Protection

EAPS and GERP (recover-time <50ms)

Loopback-detection

Link Protection

FlexLink (recover-time <50ms)

RSTP/MSTP (recover-time <1s)

LACP (recover-time <10ms)

BFD

Device Protection

VRRP

Maintenance

Network Maintenance

TGLnet-based port real-time traffic, utilization and payload statistics

RFC3176 sFlow LLDP

GPON OMCI

RFC 3164 BSD syslog Protocol

Ping

Trace route

Device Management

CLI, Console interface, Telnet

SNMPv1/v2/v3

RMON (Remote Monitoring)

NTP

NGBNView

Switching Capacity

88Gbps

Forwarding Capacity

65.5Mpps

Service Port

8*PON interface,  2*SFP interface, 2*SFP+ interface, 1*GE interface

Power Supply

AC: input 90～264V　47/63Hz；

Power Consumption

≤78W

Dimensions (W x L x H)

385X307X180

Weight (Full-Loaded)

≤10kg

Environmental Requirements

Working temperature:-20°C～65°C

Storage temperature: -40°C～85°C

Relative humidity: 10%～90%, non-condensing
